(627)- 0090 P10SA4
Sleeve Yoke Assembly: Combination: U.J. Cross 0090-GX600WP
TATA 2516, 3516
(626)- 0090 P10SA3 SLEEVE YOKE ASSEMBLY
30 SPLINE Φ49 || 41.27 X 125.85 || 4127 1258 0000 1305
0090-GX600WP || 0090-P10CHB(SERRATED-150) || 0090-P10SY30
TATA 2516,3516
(625)- 0090 P10SA2 SLEEVE YOKE ASSEMBLY
0090-GX600WP || 0090-P10CH150 (ROUND-150) || 0090-P10SY30
(624)- 0090 P10SA1 SLEEVE YOKE AASEMBLY
0090-GX600WP || 0090-P10CH130 (ROUND-130) || 0090-P10SY30
(623)- 1550 P24SA2 || SLEEVE YOKE ASSEMBLY
27 SPLINES Φ45 || 34.91 X 126.10 || 3491 1261 0000 1291
1550-GX10WP || 1550-P24CH8 (ROUND-130) || 1550-P24SY27
TATA 1109
(622)- 1550 P24SA1 SLEEVE YOKE ASSEMBLY
1550-GX10WP || 1550-P24CH6 ( ROUND-120) || 1550-P24SY27
(621)- 1480 P20SA SLEEVE YOKE ASSEMBLY
34.91 X 106.20 || 3491 1062 0000 1092
1480-GX11 || 1480-P17CH (ROUND-120) || 1480-P20SY24
TATA 709, 909
(620)- 0103 P21SA SLEEVE YOKE ASSEMBLY
22 SPLINE Φ24 || 22.02 X 54.90 || 2202 5490 0000 5730
0103-GX99WP || 0103-P21CH (SQUARE) || 0103-P21SY22
TATA ACE MAGIC
(619)- 1710 P13SA3 SLEEVE YOKE ASSEMBLY
16 SPLINES Φ63 || 49.20 X 154.80 || 4920 1548 0000 1679
1710-GX5280VX || 1710-P13CHB (SERRATED-150) || 1710-P13SY16B
TATA 4018 O/M
(618)- 1710 P13SA2 SLEEVE YOKE ASSEMBLY
1710-GX5280VX || 1710-P13CH8 (ROUND 165) || 1710-P13SY16B
(617)- 1710 P13SA1 SLEEVE YOKE ASSEMBLY
1710-GX5280VX || 1710-P13CH180 (SERRATED-180) || 1710-P13SY16B
(616)- 1550 K08SA SLEEVE YOKE ASSEMBLY
16 SPLINES Φ44 || 34.91 X 126.10 || 3491 1261 0000 1291
1550-GX10WP || 1550-K08CH (SQUARE) || 1550-K08SY16
LEYLAND TUSKER
(615)- 1480 P17SA40 SLEEVE YOKE ASSEMBLY
16 SPLINES Φ40 || 3491 X 106.20 || 3491 1062 0000 1092
1480-GX11 || 1480-P17CH (ROUND-120) || 1480-P17SY1640
TATA 410 BS III
(614)- 1480 P17SA38 SLEEVE YOKE ASSEMBLY
16 SPLINES Φ38 || 34.91 X 106.20 || 3491 1062 0000 1092
1480-GX11 || 1480-P17CH(ROUND-120) || 1480-P17SY1638
(613)- 1410 P15SA SLEEVE YOKE ASSEMBLY
16 SPLINES Φ35 || 30.19 X 106.15 || 3019 1061 0000 1091
1410-GX60 || 1410-P18CH (ROUND-120) || 1410-P15SY16
TATA 407 TURBO
(612)- 1410 G01SA SLEEVE YOKE ASSEMBLY
16 SPLINES Φ38 || 30.19 X 106.15 || 3019 1061 0000 1091
1410-GX60 || 1410-G01CH (SQUARE) || 1410-G01SY16
EICHER CANTER
(611)- 1312 P04SA SLEEVE YOKE ASSEMBLY
16 SPLINES Φ51 || 46.06 X 120.00 X 69.10 || 4606 1200 6910 7510
1312-GX104VX || 1312-P04CH(ROUND-120) || 1312-P04SY16
TATA 1312, DUMPER
(610)- 1310 168SA SLEEVE YOKE ASSEMBLY
16 SPLINE Φ32 || 27.00 X 81.60 || 2700 8160 0000 8460
1310-GX15MVX || 1310-R01CH (SQUARE) || 1310-SY168
MAHINDRA JEEP 7" , MAX PICKUP
(609)- 1310 155SA SLEEVE YOKE ASSEMBLY
1310-GX15MVX || 1310-R01CH(SQUARE) || 1310-SY155
MAHINDRA BOLERO DI, SLX, FLAT BED, MAXI TRUCK
(608)- 1310 154SA (SLEEVE YOKE ASSEMBLY)
16 SPLINE Φ32 27.00 X 81.60 2700 8160 0000 8460
1310-GX15MVX / 1310-R01CH (SQUARE) / 1310-SY154
(607)- 1310 153SA SLEEVE YOKE ASSEMBLY
1310-GX15MVX / 1310-R01CH(SQUARE) / 1310-SY153
MAHINDRA BOLERO
(606)- 0407 P16SA
16 SPLINE Φ35 SLEEVE YOKE ASSEMBLY 30.06 X 81.60 3006 8160 0000 8460
0407-GX02 0407-P16CH (ROUND-100) 0407-P16SY16
TATA 407 O/M Ref No: NA/FY013/000/000/000
(605)- 0090 K02SA2 SLEEVE YOKE ASSEMBLY
16 SPLINE Φ 50 || 41.27 X 125.85 || 4127 1258 0000 1305
0090-GX600WP || 0090-K02CHS (SQUARE) || 0090-K02SY16
LEYLAND 2214 || Ref. No.: NA
(604)- 0090 K02SA1 (SLEEVE YOKE ASSEMBLY)
0090-GX600WP || 0090-K02CH (ROUND-175) || 0090- K02SY16
LEYLAND 2214 || Ref.No.: NA
