(391)- 0090 P10PC41S COUPLING
41 SPLINE Φ54
4 HOLES, HEX 19, Φ12.80 || HEIGHT 87/3.42" , SEAL 76 (SQUARE)
TATA 2416 TC, LEYLAND INTER AXLE 109 || Ref.No.: NA/526/713/914/22A
(390)- 0490 P14PC41X COUPLING
41 SPLINES Φ54
4 HOLES, HEX 22, Φ15 || DIA 180/7.08", HEIGHT 111/4.37", SEAL 76
TATA 2518, 4018, LEYLAND 2516 || Ref.No.: NA/000/787/708/361
(389)- 0090 P10PC41B COUPLING
8 HOLES, HEX 24, Φ16.10 || DIA 165/6.50" , HEIGHT 93/3.66", SEAL 76
TATA 2516,2518,4018 || Ref.No.: NA/550/719/706/22D
(388)- 0090 P10PC41A COUPLING
8 HOLES, HEX 17, Φ10.10 || DIA 130/5.11", HEIGHT 93/3.66", SEAL 76
TATA 2515, 2516,3516 || Ref.No.: NA/524/712/779/002
(387)- 0090 P10PC41C COUPLING
8 HOLES, HEX 24, Φ16.10 || DIA 165/6.50", HEIGHT 108/4.25", SEAL 76
TATA 22516, 2518,4018 || Ref.No.: NA/527/776/705/339
(386)- 0090 K02PC41 COUPLING
8 HOLES, HEX 15, Φ9.80 || DIA 175/6.88", HEIGHT 89/3.50", SEAL 76
LEYLAND 2214, 3516, 2516 || Ref.No.: NA/544/741/765/156
(385)- 0403 P09PC39X (0403 P09CB/P09 PCB)
39 SPLINE Φ51
4 HOLES, HEX 19, Φ12.80 || DIA 150//5.90", HEIGHT 92/3.62", SEAL 70 (BIG)
TATA 2518, 4018, LEYLAND 2516 || Ref.No.: NA/011C/7028/912/318A
(383)- 0090 P10PC39S COUPLING
4 HOLES, HEX 19, Φ13 || HEIGHT 88/3.46", SEAL 76 (SQUARE)
TATA 2516 TC || Ref.No.: NA/525/710/915/021A
(382)- 0090 P10PC39B (COUPLING)
8 HOLES, HEX 17, Φ10.20 || DIA 130/5.11", HEIGHT 86/3.39", SEAL 76
TATA 2515 EX, 2516 INTER AXLE || Ref.No.: NA/535/708/775/021
(381)- 0090 P10PC34S COUPLING
34 SPLINE Φ45
4 HOLES, HEX 19, Φ13 || HEIGHT 86/3.38", SEAL 63 (SQUARE)
LEYLAND 2516 INTER AXLE 109 || Ref.No.: NA/494/000/917/000
(380)- 1480 J01PC32
Pinion Coupling End Yoke Type: Threaded (Mating U.J. Cross No. 1480-GX11)
JCB 3D
(379)- 0403 P09CC34X COUPLING
34 SPLINES Φ45 || MATING 0090-P10FT34
4 HOLES, HEX 19, Φ12.80 || DIA 150/5.90", HEIGHT 80/3.14", SEAL 65
TATA 2518, 1613 TURBO BSIII, 1616 || Ref.No.: NA/004/750/710/313A
(378)- 0325 P08CC34 (0325 P08CC/P08 CC)
34 SPLINES Φ45 COUPLING || MATING 0090-P10FT34
8 HOLES/5.11", HEIGHT 80/3.14", SEAL 64
TATA 2515 CEX (EQ90) || Ref.No.: NA/474/757/778/332
(377)- 0090 P10PC39A COUPLING
8 HOLES, HEX 17, Φ10.20 || DIA 130/5.11" , HEIGHT 88/3.46", SEAL 71
TATA 2516,2515,3616 INTER AXLE || Ref.No.: NA/523/000/748/020
(376)- 0090 P10CC34 (0090 P10CC/P10 CC)
34 SPLINE Φ45 COUPLING || MATING 0090-P10FT34
8 HOLES, HEX 17, Φ10.20 || DIA 130 / 5.11", HEIGHT 77/3.03", SEAL 66
TATA 2516, 2518,3516 || Ref.No. INSKU-9010017/480/705/365/019
(375)- 1480 J01PC35
JCB-3DX
(374)- 2045 K14GC28 COUPLING
28 SPLINES Φ45
8 HOLES, HEX 15, Φ9.80 || DIA 175/6.88", HEIGHT 115/4.52", SEAL 54
LEYLAND U TRUCK, 2516, 3516, ZF/BELL TYPE || Ref.No.: 1681 Z5B/446/756/745/153A
(373)- 2040 P11PC26 COUPLING
26 SPLINE Φ55
8 HOLES, HEX 24, Φ16.20 ll DIA 165/6.50", HEIGHT 77/3.03", SEAL 68
TATA 4018 ll Ref.No.: NA/533/KKL/805/22E
(372)- 1312 P07CC26 (1312 P07CC/P07 CC)
26 SPLINES Φ55 COUPLING || MATING 1312 P03FT26
8 HOLES, HEX 17, Φ10.20 || DIA 130/5.11", HEIGHT 92/3.62", SEAL 69
TATA 2416 || Ref.No.: INSKU-100847, 2632 4110 5103/601/746/774/277
(371)- 0490 P14GC26X (0490 P14GC/P14 GC)
26 SPLINES Φ55
DIA 150/5.90", HEIGHT 109/4.29", SEAL 68
Ref.No.: 2715 2620 0126/018/773/701/319
(370)- 0490 P14CC26X COUPLING
26 SPLINES Φ55 || MATING 0490-P14FT26 || 0490-P14FTW26
4 HOLES, HEX 19, Φ13 DIA 150/5.90" , HEIGHT 94/3.70", SEAL 72
TATA 4018 || Ref.No.: 2715 2620 0126/006/786/702/000
(369)- 0403 P09PC26XC COUPLING
4 HOLES, HEX 19, Φ12.80 || DIA 150/5.90", HEIGHT 61/2.40", SEAL 68
TATA 3118, 3516, 2516 LPT, 2518 LPT 1613 TURBO BSIII, 1616 || Ref.No.: 90-1-0017/05A/790/919C/316A
(368)- 0403 P09PC26X (0403 P09PCS/P09 PCS)
TATA 3118,3516,2516 LPT, 2518 LPT 1613 TURBO BSIII, 1616 || Ref.No.: 90-1-0017/005/716/919/316
(367)- 1312 P03PC26 (1312 P03PC/P03 PC)
26 SPLINES Φ55 COUPLING
8 HOLES, HEX17, Φ10.20 || DIA 130/5.11", HEIGHT 61/2.40", SEAL 68
TAT 1312 || Ref.No.: 2676 3520 0110, 2576 3530 0110/522/704/206/18
